Topic 3-02: Local GREAT analysis

Zuguang Gu

2025-05-31

Source: vignettes/topic3_03_local_GREAT.Rmd
topic3_03_local_GREAT.Rmd

Basic usage

First let’s load the rGREAT package and generate a set of random regions:

library(rGREAT)
set.seed(123)
gr = randomRegions(nr = 1000, genome = "hg19")

Besides the input regions, GREAT analysis needs two types of input data: the gene sets and TSS source. Thus the second argument in great() corresponds to the gene sets, and the third argument corresponds to the source of TSS.

rGREAT has integrated many gene sets and genomes.

The second argument (the gene set) supports:

  1. a name of a pre-defined gene set collection
  2. a list of genes

The third argument (the source of TSSs) supports

  1. genome version,
  2. a GRanges() object with an additional meta column gene_id
  3. other not for end users.
res = great(gr, "MSigDB:H", "hg19")

Following functions are very similar as in online GREAT.

## GRanges object with 869 ranges and 2 metadata columns:
##         seqnames            ranges strand | annotated_genes    dist_to_TSS
##            <Rle>         <IRanges>  <Rle> | <CharacterList>  <IntegerList>
##     [1]     chr1   9204434-9208784      * |     GPR157,H6PD  -15205,-86079
##     [2]     chr1   9853594-9859363      * |   PIK3CD,CLSTN1   141804,25187
##     [3]     chr1 10862809-10871681      * |  CASZ1,C1orf127   -6076,170413
##     [4]     chr1 12716970-12723206      * | AADACL4,AADACL3   12404,-52912
##     [5]     chr1 13814692-13823250      * | PRAMEF17,LRRC38    98604,16992
##     ...      ...               ...    ... .             ...            ...
##   [865]     chrY 16384799-16389852      * |   TMSB4Y,NLGN4Y 569352,-244636
##   [866]     chrY 16842593-16846893      * |          NLGN4Y         208105
##   [867]     chrY 16998750-17003225      * |          NLGN4Y         364262
##   [868]     chrY 24401612-24406252      * |   RBMY1E,RBMY1F  -72523,-48754
##   [869]     chrY 26206997-26215445      * |            DAZ2         841416
##   -------
##   seqinfo: 26 sequences from an unspecified genome; no seqlengths
plotRegionGeneAssociations(res, term_id = "HALLMARK_APOPTOSIS")

# shinyReport(res)

The following gene sets are directly supported:

  • "GO:BP": Biological Process.
  • "GO:CC": Cellular Component.
  • "GO:MP": Molecular Function.

Note MSigDB genes are only for human.

  • "msigdb:H" Hallmark gene sets.
  • "msigdb:C1" Positional gene sets.
  • "msigdb:C2" Curated gene sets.
  • "msigdb:C2:CGP" C2 subcategory: chemical and genetic perturbations gene sets.
  • "msigdb:C2:CP" C2 subcategory: canonical pathways gene sets.
  • "msigdb:C2:CP:KEGG" C2 subcategory: KEGG subset of CP.
  • "msigdb:C2:CP:PID" C2 subcategory: PID subset of CP.
  • "msigdb:C2:CP:REACTOME" C2 subcategory: REACTOME subset of CP.
  • "msigdb:C2:CP:WIKIPATHWAYS" C2 subcategory: WIKIPATHWAYS subset of CP.
  • "msigdb:C3" Regulatory target gene sets.
  • "msigdb:C3:MIR:MIRDB" miRDB of microRNA targets gene sets.
  • "msigdb:C3:MIR:MIR_LEGACY" MIR_Legacy of MIRDB.
  • "msigdb:C3:TFT:GTRD" GTRD transcription factor targets gene sets.
  • "msigdb:C3:TFT:TFT_LEGACY" TFT_Legacy.
  • "msigdb:C4" Computational gene sets.
  • "msigdb:C4:CGN" C4 subcategory: cancer gene neighborhoods gene sets.
  • "msigdb:C4:CM" C4 subcategory: cancer modules gene sets.
  • "msigdb:C5" Ontology gene sets.
  • "msigdb:C5:GO:BP" C5 subcategory: BP subset.
  • "msigdb:C5:GO:CC" C5 subcategory: CC subset.
  • "msigdb:C5:GO:MF" C5 subcategory: MF subset.
  • "msigdb:C5:HPO" C5 subcategory: human phenotype ontology gene sets.
  • "msigdb:C6" Oncogenic signature gene sets.
  • "msigdb:C7" Immunologic signature gene sets.
  • "msigdb:C7:IMMUNESIGDB" ImmuneSigDB subset of C7.
  • "msigdb:C7:VAX" C7 subcategory: vaccine response gene sets.
  • "msigdb:C8" Cell type signature gene sets.

The "GO:" and “msigdb:” prefix can be removed when specifying in great().

Setting genome background

Background can be set via backgroud and excluce arguments.

gap = getGapFromUCSC("hg19", paste0("chr", c(1:22, "X", "Y")))
great(gr, "MSigDB:H", "hg19", exclude = gap)

great(gr, "GO:BP", "hg19", background = paste0("chr", 1:22))
great(gr, "GO:BP", "hg19", exclude = c("chrX", "chrY"))

Restricting the anallysis in a certain type of genome background helps to reduce the false positives. Examples are:

  • excluding unmappable regions
  • regions with certain level of CG density
  • regions with certain level of gene densities
  • exons (coding regions)

A very useful case is to perform GREAT only in promoter regions or in distal regions from gene:

great(gr, ..., background = promoters)
great(gr, ..., background = distal)
great(gr, ..., background = gene_body)

Question: how to obtain intergenic and distal regions from TSS?

Extend from the complete gene

By default genes are extended only from TSS. In the newer version of rGREAT (>= 2.10.0), you can also extend from the complete gene bodies.

great(gr, "BP", "hg19", extend_from = "gene")

Using other gene sets

great() supports self-defined gene sets. Just make sure genes in gene models have the same ID type as in gene sets.

More gene sets can be set as a list of gene vectors. For most organisms, EntreZ IDs should be used as the gene ID type in gene sets.

From a .gmt file:

gs = read_gmt(url("http://dsigdb.tanlab.org/Downloads/D2_LINCS.gmt"),
    from = "SYMBOL", to = "ENTREZ", orgdb = "org.Hs.eg.db")
gs[1:2]
## $GSK429286A
##  [1] "5566"  "9475"  "81788" "6093"  "5562"  "26524" "5592"  "5979"  "640"
## [10] "5567"  "3717"  "5613"  "23012" "695"   "3718"
##
## $`BS-181`
##  [1] "122011" "1452"   "1022"   "7272"   "1454"   "1453"   "65975"  "147746"
##  [9] "1859"   "1195"   "1196"   "9149"   "57396"  "5261"
great(gr, gs, "hg19")
## 916 regions are associated to 1400 genes' extended TSSs.
##   TSS source: TxDb.Hsapiens.UCSC.hg19.knownGene
##   Genome: hg19
##   OrgDb: org.Hs.eg.db
##   Gene sets: self-provided
##   Background: whole genome excluding gaps
## Mode: Basal plus extension
##   Proximal: 5000 bp upstream, 1000 bp downstream,
##   plus Distal: up to 1000000 bp

KEGG pathways:

df = read.table(url("https://rest.kegg.jp/link/pathway/hsa"), sep = "\t")
df[, 1] = gsub("hsa:", "", df[, 1])
df[, 2] = gsub("path:",  "", df[, 2])
gs_kegg = split(df[, 1], df[, 2])
gs_kegg[1:2]
## $hsa00010
##  [1] "10327"  "124"    "125"    "126"    "127"    "128"    "130"    "130589"
##  [9] "131"    "160287" "1737"   "1738"   "2023"   "2026"   "2027"   "217"
## [17] "218"    "219"    "2203"   "221"    "222"    "223"    "224"    "226"
## [25] "229"    "230"    "2538"   "2597"   "26330"  "2645"   "2821"   "3098"
## [33] "3099"   "3101"   "387712" "3939"   "3945"   "3948"   "441531" "501"
## [41] "5105"   "5106"   "5160"   "5161"   "5162"   "5211"   "5213"   "5214"
## [49] "5223"   "5224"   "5230"   "5232"   "5236"   "5313"   "5315"   "55276"
## [57] "55902"  "57818"  "669"    "7167"   "80201"  "83440"  "84532"  "8789"
## [65] "92483"  "92579"  "9562"
##
## $hsa00020
##  [1] "1431"  "1737"  "1738"  "1743"  "2271"  "3417"  "3418"  "3419"  "3420"
## [10] "3421"  "4190"  "4191"  "47"    "48"    "4967"  "50"    "5091"  "5105"
## [19] "5106"  "5160"  "5161"  "5162"  "55753" "6389"  "6390"  "6391"  "6392"
## [28] "8801"  "8802"  "8803"
great(gr, gs_kegg, "hg19")
## 916 regions are associated to 1400 genes' extended TSSs.
##   TSS source: TxDb.Hsapiens.UCSC.hg19.knownGene
##   Genome: hg19
##   OrgDb: org.Hs.eg.db
##   Gene sets: self-provided
##   Background: whole genome excluding gaps
## Mode: Basal plus extension
##   Proximal: 5000 bp upstream, 1000 bp downstream,
##   plus Distal: up to 1000000 bp

Other organisms which have TxDb packages

On Bioconductor, there are a family of annotation packages with name TxDb.*.db. These packages contain sources of TSS definitions.

All supported txdb.*.db packages:

tb = rGREAT:::BIOC_ANNO_PKGS
knitr::kable(tb[!duplicated(tb$genome_version_in_txdb), ])
species_name species_latin taxon_id txdb gene_id_in_txdb genome_version_in_txdb orgdb primary_gene_id_in_orgdb chromosome_prefix
1 human Homo sapiens 9606 TxDb.Hsapiens.UCSC.hg18.knownGene Entrez Gene ID hg18 org.Hs.eg.db Entrez Gene ID chr
2 human Homo sapiens 9606 TxDb.Hsapiens.UCSC.hg19.knownGene Entrez Gene ID hg19 org.Hs.eg.db Entrez Gene ID chr
3 human Homo sapiens 9606 TxDb.Hsapiens.UCSC.hg38.knownGene Entrez Gene ID hg38 org.Hs.eg.db Entrez Gene ID chr
5 mouse Mus musculus 10090 TxDb.Mmusculus.UCSC.mm10.knownGene Entrez Gene ID mm10 org.Mm.eg.db Entrez Gene ID chr
7 mouse Mus musculus 10090 TxDb.Mmusculus.UCSC.mm39.refGene Entrez Gene ID mm39 org.Mm.eg.db Entrez Gene ID chr
8 mouse Mus musculus 10090 TxDb.Mmusculus.UCSC.mm9.knownGene Entrez Gene ID mm9 org.Mm.eg.db Entrez Gene ID chr
9 rat Rattus norvegicus 10116 TxDb.Rnorvegicus.UCSC.rn4.ensGene Ensembl gene ID rn4 org.Rn.eg.db Entrez Gene ID chr
10 rat Rattus norvegicus 10116 TxDb.Rnorvegicus.UCSC.rn5.refGene Entrez Gene ID rn5 org.Rn.eg.db Entrez Gene ID chr
11 rat Rattus norvegicus 10116 TxDb.Rnorvegicus.UCSC.rn6.refGene Entrez Gene ID rn6 org.Rn.eg.db Entrez Gene ID chr
12 rat Rattus norvegicus 10116 TxDb.Rnorvegicus.UCSC.rn7.refGene Entrez Gene ID rn7 org.Rn.eg.db Entrez Gene ID chr
13 chicken Gallus gallus 9031 TxDb.Ggallus.UCSC.galGal4.refGene Entrez Gene ID galGal4 org.Gg.eg.db Entrez Gene ID chr
14 chicken Gallus gallus 9031 TxDb.Ggallus.UCSC.galGal5.refGene Entrez Gene ID galGal5 org.Gg.eg.db Entrez Gene ID chr
15 chicken Gallus gallus 9031 TxDb.Ggallus.UCSC.galGal6.refGene Entrez Gene ID galGal6 org.Gg.eg.db Entrez Gene ID chr
16 rhesus Macaca mulatta 9544 TxDb.Mmulatta.UCSC.rheMac10.refGene Entrez Gene ID rheMac10 org.Mmu.eg.db Entrez Gene ID chr
17 rhesus Macaca mulatta 9544 TxDb.Mmulatta.UCSC.rheMac3.refGene Entrez Gene ID rheMac3 org.Mmu.eg.db Entrez Gene ID chr
18 rhesus Macaca mulatta 9544 TxDb.Mmulatta.UCSC.rheMac8.refGene Entrez Gene ID rheMac8 org.Mmu.eg.db Entrez Gene ID chr
19 worm Caenorhabditis elegans 6239 TxDb.Celegans.UCSC.ce11.refGene Entrez Gene ID ce11 org.Ce.eg.db Entrez Gene ID chr
21 dog Canis familiari 9615 TxDb.Cfamiliaris.UCSC.canFam3.refGene Entrez Gene ID canFam3 org.Cf.eg.db Entrez Gene ID chr
22 dog Canis familiari 9615 TxDb.Cfamiliaris.UCSC.canFam4.refGene Entrez Gene ID canFam4 org.Cf.eg.db Entrez Gene ID chr
23 dog Canis familiari 9615 TxDb.Cfamiliaris.UCSC.canFam5.refGene Entrez Gene ID canFam5 org.Cf.eg.db Entrez Gene ID chr
24 pig Sus scrofa 9823 TxDb.Sscrofa.UCSC.susScr11.refGene Entrez Gene ID susScr11 org.Ss.eg.db Entrez Gene ID chr
25 pig Sus scrofa 9823 TxDb.Sscrofa.UCSC.susScr3.refGene Entrez Gene ID susScr3 org.Ss.eg.db Entrez Gene ID chr
26 yeast Saccharomyces cerevisiae 4932 TxDb.Scerevisiae.UCSC.sacCer2.sgdGene SGD Gene ID sacCer2 org.Sc.sgd.db SGD Gene ID chr
27 yeast Saccharomyces cerevisiae 4932 TxDb.Scerevisiae.UCSC.sacCer3.sgdGene SGD Gene ID sacCer3 org.Sc.sgd.db SGD Gene ID chr
28 chimp Pan troglodytes 9598 TxDb.Ptroglodytes.UCSC.panTro4.refGene Entrez Gene ID panTro4 org.Pt.eg.db Entrez Gene ID chr
29 chimp Pan troglodytes 9598 TxDb.Ptroglodytes.UCSC.panTro5.refGene Entrez Gene ID panTro5 org.Pt.eg.db Entrez Gene ID chr
30 chimp Pan troglodytes 9598 TxDb.Ptroglodytes.UCSC.panTro6.refGene Entrez Gene ID panTro6 org.Pt.eg.db Entrez Gene ID chr
31 fruitfly Drosophila melanogaster 7227 TxDb.Dmelanogaster.UCSC.dm3.ensGene Ensembl gene ID dm3 org.Dm.eg.db Entrez Gene ID chr
32 fruitfly Drosophila melanogaster 7227 TxDb.Dmelanogaster.UCSC.dm6.ensGene Ensembl gene ID dm6 org.Dm.eg.db Entrez Gene ID chr
33 zebrafish Danio rerio 7955 TxDb.Drerio.UCSC.danRer10.refGene Entrez Gene ID danRer10 org.Dr.eg.db Entrez Gene ID chr
34 zebrafish Danio rerio 7955 TxDb.Drerio.UCSC.danRer11.refGene Entrez Gene ID danRer11 org.Dr.eg.db Entrez Gene ID chr
35 cattle Bos taurus 9913 TxDb.Btaurus.UCSC.bosTau8.refGene Entrez Gene ID bosTau8 org.Bt.eg.db Entrez Gene ID chr
36 cattle Bos taurus 9913 TxDb.Btaurus.UCSC.bosTau9.refGene Entrez Gene ID bosTau9 org.Bt.eg.db Entrez Gene ID chr
37 thale cress Arabidopsis thaliana 3702 TxDb.Athaliana.BioMart.plantsmart51 TAIR ID araTha org.At.tair.db TAIR ID

For these packages, users only need to specify the “genome version”:

great(gr, "BP", "mm10")
great(gr, "BP", "rn7")

Note gr should have chr prefix for most of the organisms.

Use MSigDB gene sets for other organisms

Taking chimpanzee as an example. There is an TxDb on Bioconductor.

gr = randomRegions(nr = 1000, genome = "panTro6")
library(GSEAtopics)
gs = get_msigdb(version = "2024.1.Hs", collection = "h.all")
gs2 = gs_map_to_orthologues(gs, from = "Homo.sapiens", to = "Pan.troglodytes")

great(gr, gs2, "panTro6")
## 988 regions are associated to 662 genes' extended TSSs.
##   TSS source: TxDb.Ptroglodytes.UCSC.panTro6.refGene
##   Genome: panTro6
##   OrgDb: org.Pt.eg.db
##   Gene sets: self-provided
##   Background: whole genome excluding gaps
## Mode: Basal plus extension
##   Proximal: 5000 bp upstream, 1000 bp downstream,
##   plus Distal: up to 1000000 bp

Other organisms who have TxDb object on AnnotationHub

For some other organisms, although they don’t have a TxDb package on Bioconductor, but they have a TxDb object on AnnotationHub:

library(AnnotationHub)
ah = AnnotationHub()
query(ah, "TxDb")
## AnnotationHub with 511 records
## # snapshotDate(): 2024-10-28
## # $dataprovider: UCSC, FungiDB, TriTrypDB, PlasmoDB, MicrosporidiaDB, ToxoDB...
## # $species: Homo sapiens, Rattus norvegicus, Macaca mulatta, Gallus gallus, ...
## # $rdataclass: TxDb, SQLiteFile, FaFile, ChainFile
## # additional mcols(): taxonomyid, genome, description,
## #   coordinate_1_based, maintainer, rdatadateadded, preparerclass, tags,
## #   rdatapath, sourceurl, sourcetype
## # retrieve records with, e.g., 'object[["AH52245"]]'
##
##              title
##   AH52245  | TxDb.Athaliana.BioMart.plantsmart22.sqlite
##   AH52246  | TxDb.Athaliana.BioMart.plantsmart25.sqlite
##   AH52247  | TxDb.Athaliana.BioMart.plantsmart28.sqlite
##   AH52248  | TxDb.Btaurus.UCSC.bosTau8.refGene.sqlite
##   AH52249  | TxDb.Celegans.UCSC.ce11.refGene.sqlite
##   ...        ...
##   AH114096 | TxDb.Mmusculus.UCSC.mm39.refGene.sqlite
##   AH116719 | TxDb.Hsapiens.UCSC.hg38.refGene.sqlite
##   AH116720 | TxDb.Mmusculus.UCSC.mm39.refGene.sqlite
##   AH117076 | TxDb.Hsapiens.UCSC.hg38.knownGene.sqlite
##   AH117077 | TxDb.Mmusculus.UCSC.mm39.knownGene.sqlite

But it seems many of those organisms are microbes. I will not introduce it here.

Other organisms who do not have TxDb objects

Get TSS from NCBI

We need to first know the “accession number” of an organism’s genome. Taking dolphin as an example, its web page on NCBI Genome is https://www.ncbi.nlm.nih.gov/datasets/genome/GCF_011762595.1/. In rGREAT, there is a getGenomeDataFromNCBI() function which can automatically retrieve gene definitions from NCBI.

genes = getGenomeDataFromNCBI("GCF_011762595.1", return_granges = TRUE)
genes
## GRanges object with 19081 ranges and 1 metadata column:
##           seqnames        ranges strand |     gene_id
##              <Rle>     <IRanges>  <Rle> | <character>
##       [1]        1 234018-239154      + |   101335869
##       [2]        1 241768-255021      + |   101336161
##       [3]        1 259970-287776      + |   101336448
##       [4]        1 288745-298452      + |   101336738
##       [5]        1 325391-327082      - |   101321052
##       ...      ...           ...    ... .         ...
##   [19077]       MT    9921-10217      + |     7412053
##   [19078]       MT   10211-11588      + |     7412054
##   [19079]       MT   11790-13610      + |     7412055
##   [19080]       MT   13594-14121      - |     7412056
##   [19081]       MT   14195-15334      + |     7412057
##   -------
##   seqinfo: 23 sequences from an unspecified genome

With it, the chromosome lengths are also retrieved:

seqlengths(genes)
##         1         2         3         4         5         6         7         8
## 183742880 176472748 171421769 144183200 137487549 115599616 114015307 108430135
##         9        10        11        12        13        14        15        16
## 105335178 102812509 102167733  89330967  88485069  88483154  86293990  83508544
##        17        18        19        20        21         X        MT
##  78442772  78151963  58636127  58467291  35682248 128693445     16388

As we have already introduced, retrieve GO gene sets for an organism is easy:

library(AnnotationHub)
ah = AnnotationHub()
hit = query(ah, c("Tursiops truncatus", "OrgDb"))
orgdb = ah[[ hit$ah_id ]]

library(GSEAtopics)
gs = get_GO_gene_sets_from_orgdb(orgdb, "BP")
gs[1:2]
## $`GO:0000002`
##  [1] "101315666" "101325920" "101326047" "101328885" "101329040" "101329473"
##  [7] "101330306" "101330328" "101332655" "101336906"
##
## $`GO:0000012`
## [1] "101321216" "101324135" "101337120"

Note genes is set to the argument tss_source:

gr = randomRegions(nr = 1000, seqlengths =  seqlengths(genes))
great(gr, gs, genes)
## 1000 regions are associated to 1614 genes' extended TSSs.
##   TSS source: self-provided
##   Genome: unknown
##   Gene sets: self-provided
##   Background: whole genome
## Mode: Basal plus extension
##   Proximal: 5000 bp upstream, 1000 bp downstream,
##   plus Distal: up to 1000000 bp

Remember to double check the format of chromosome names in gr and in genes.

Practice

Practice 1

Run local GREAT analysis with a list of TFBS from UCSC table browser:

clade: Mammal
genome: Human
assembly: GRCh37/hg19
group: Regulation
track: ENCODE 3 TFBS
table: 22Rv1 ZFX (encTfChipRkENCFF445OFX)

In the “output format” field, select “BED - browser extensible data”, then click the button “get output”. In the next page, click the button “get BED”.

Use 1. the GO BP gene sets and 2. KEGG pathways.
